7.0ft Wide 7-Rail Farm Gate Kit
Product Description
7.0ft Wide 7-Rail Farm Gate Kit
Metal Agricultural Gates are important to a business in a rural setting, they enable control of livestock and vehicles and help in the prevention of theft of valuable assets. This type of metal field gate can take a battering whether that is from vehicles accidentally hitting them, large animals such as cows and bulls kicking or ramming them, or just from the weather and wear and tear generally so they need to be well made and very sturdy. A metal gate is the best choice for this setting.
The Farm Gate Kits from First Fence are available in the following widths 3ft, 4ft, 5ft, 6ft, 7ft, 8ft, 9ft, 10ft, 11ft, 12ft, 13ft, 14ft, 15ft and 16ft. Manufactured from galvanised steel they are a classic 7-rail design that is seen frequently as a gateway to fields and farm premises. The horizontal rails are welded to 50mm x 50mm and 50mm x 25mm box sections which brace the gate and make it a very sturdy and heavy-duty construction. The rails at the lower half of the gate are closer together and this helps to prevent small livestock from escaping the field or enclosure.
The metal farm gate comes with a Spring Bolt Kit to securely close it. This comprises a Slider Latch Bar, a compression spring, M20 Flat Washer and a tension pin. This does not require bolting to the gate, it fits easily through the drilled holes in the structure.
The Kit includes two Adjustable Gate Eyes which enable the gate to be altered to suit a gradient or uneven ground. The two posts are 114.3mm (4.5") in overall diameter and are made of galvanised steel, the Hanging Post has two lugs to hang the leaf on.
The Farm Gate Kit is a dig in format product and will need to be concreted into the ground substance. First Fence stocks Post Mix that is perfect for this job. The ground clearance of the gate may vary depending on the ground conditions.
All items within the kit are available to be purchased separately.
Get in Touch
Please get in touch if you have any questions about this product range. Our friendly sales team can be contacted by calling 01283 512111 or by using the online chat tool.
Specifications & Downloads
| Height | 1145mm |
| Total Post Length | Actual Length 2000mm [600mm Minimum Dig In] |
| Width | 2483mm [Including Posts] |
| Access Width | 2135mm |
| Weight | 50.1kg |
| Post Types | Dig In |
| Gate Hanging Side | Right or Left-hand |
| Material | Galvanised Steel |
| Finish | Galvanised |
| Post Diameter | 114.3mm [4.5"] |
What's Included
| Name | Quantity |
|---|---|
| 7-Rail Farm Gate [2135mm W] | 1 |
| Hanging Post 114.3mm OD | 1 |
| Slotted Post 114.3mm OD | 1 |
| Adjustable Gate Eye | 2 |
| Springbolt Kit | 1 |
| Black Ribbed Insert 50mm x 50mm | 1 |
| Black Ribbed Insert 50mm x 25mm | 1 |
Specifications & Downloads
| Height | 1145mm |
| Total Post Length | Actual Length 2000mm [600mm Minimum Dig In] |
| Width | 2483mm [Including Posts] |
| Access Width | 2135mm |
| Weight | 50.1kg |
| Post Types | Dig In |
| Gate Hanging Side | Right or Left-hand |
| Material | Galvanised Steel |
| Finish | Galvanised |
| Post Diameter | 114.3mm [4.5"] |
What's Included
| Name | Quantity |
|---|---|
| 7-Rail Farm Gate [2135mm W] | 1 |
| Hanging Post 114.3mm OD | 1 |
| Slotted Post 114.3mm OD | 1 |
| Adjustable Gate Eye | 2 |
| Springbolt Kit | 1 |
| Black Ribbed Insert 50mm x 50mm | 1 |
| Black Ribbed Insert 50mm x 25mm | 1 |
Product Description
7.0ft Wide 7-Rail Farm Gate Kit
Metal Agricultural Gates are important to a business in a rural setting, they enable control of livestock and vehicles and help in the prevention of theft of valuable assets. This type of metal field gate can take a battering whether that is from vehicles accidentally hitting them, large animals such as cows and bulls kicking or ramming them, or just from the weather and wear and tear generally so they need to be well made and very sturdy. A metal gate is the best choice for this setting.
The Farm Gate Kits from First Fence are available in the following widths 3ft, 4ft, 5ft, 6ft, 7ft, 8ft, 9ft, 10ft, 11ft, 12ft, 13ft, 14ft, 15ft and 16ft. Manufactured from galvanised steel they are a classic 7-rail design that is seen frequently as a gateway to fields and farm premises. The horizontal rails are welded to 50mm x 50mm and 50mm x 25mm box sections which brace the gate and make it a very sturdy and heavy-duty construction. The rails at the lower half of the gate are closer together and this helps to prevent small livestock from escaping the field or enclosure.
The metal farm gate comes with a Spring Bolt Kit to securely close it. This comprises a Slider Latch Bar, a compression spring, M20 Flat Washer and a tension pin. This does not require bolting to the gate, it fits easily through the drilled holes in the structure.
The Kit includes two Adjustable Gate Eyes which enable the gate to be altered to suit a gradient or uneven ground. The two posts are 114.3mm (4.5") in overall diameter and are made of galvanised steel, the Hanging Post has two lugs to hang the leaf on.
The Farm Gate Kit is a dig in format product and will need to be concreted into the ground substance. First Fence stocks Post Mix that is perfect for this job. The ground clearance of the gate may vary depending on the ground conditions.
All items within the kit are available to be purchased separately.
Get in Touch
Please get in touch if you have any questions about this product range. Our friendly sales team can be contacted by calling 01283 512111 or by using the online chat tool.
