2.0m High x 3.0m Wide EchoGroove Reflective Acoustic Fencing Kit
Use Our PostPro Calculation Service
Unsure if our recommended steel posts are right for you? Simply tell us about your site and height for an engineers report on post suitability:
Product Description
2.0m High x 3.0m Wide EchoGroove Reflective Acoustic Fencing Kit
Restore peace and quiet with the EchoGroove Reflective Acoustic Fencing system from First Fence. Measuring 2.0m high by 3.0m wide, this fencing kit is designed to be both durable and visually appealing, an effective solution for reducing noise in various settings.
The fence works by reflecting unwanted sound away from your property. Its smart design uses high-mass, planed tongue and groove interlocking boards to form a dense, solid barrier with minimal gaps, helping block and deflect noise efficiently.
Features and Benefits
Outstanding Noise Control: Independently tested by the University of Salford, this system delivers proven noise reduction for a more peaceful outdoor space.
High Quality Build: The distinctive "Groovy" profile features premium horizontal tongue and groove boards that fit tightly for optimal performance and a sleek, modern look.
Long Lasting Durability: All timber is pressure treated, with a manufacturer promoted 30 year expected service life, offering a robust, low maintenance solution.
Sustainably Made: Crafted in the UK using responsibly sourced, high grade timber.
Improved Privacy & Security: Standing at 1.8m (approx. 6ft), the solid structure ensures strong privacy and acts as a secure boundary.
Function and Performance
This is a reflective acoustic barrier, designed to deflect sound waves away from the protected area. It has undergone rigorous testing and is certified to meet key British and European standards:
BS EN 1793-2: Assesses airborne sound insulation for road traffic noise barriers. This system achieves a Category B3 rating, indicating excellent sound-blocking performance.
BS EN 1794-1 & 1794-2: Covers non-acoustic performance, verifying the barrier’s mechanical strength, wind resistance, and overall safety.
Highways Sector Scheme 2C: Certified for the prefabrication of environmental barriers, making it suitable for use along public roads and highways.
Applications
This is a reflective acoustic barrier, designed to deflect sound waves away from the protected area. It has undergone rigorous testing and is certified to meet key British and European standards:
BS EN 1793-2: Assesses airborne sound insulation for road traffic noise barriers. This system achieves a Category B3 rating, indicating excellent sound-blocking performance.
BS EN 1794-1 & 1794-2: Covers non acoustic performance, verifying the barrier’s mechanical strength, wind resistance, and overall safety.
Highways Sector Scheme 2C: Certified for the prefabrication of environmental barriers, making it suitable for use along public roads and highways.
This 2.0m high x 3.0m wide kit has all the components needed for one complete bay, allowing you to create a continuous, high performance barrier tailored to your project requirements.
Function and Style
These panels not only look great but provide the very best solution to tackle excessive and unwanted noise across many applications, ranging from residential, education, transport, commercial and industrial. This acoustic fencing works by creating an adequate barrier to disturb and repel any unwanted sound. This can have an extreme effect noticeably reducing noise levels and minimising any previous disruption. Aside from noise management, acoustic fence panels offer greater levels of privacy and are more aesthetically pleasing than industrial-styled security fencing.
First Fence also has a range called EchoReflect and EchoAbsorb, why not take a look today? Also available is a range of Sound Absorption Barriers and accessories.
Get in touch
If you have any questions about this product line, please get in touch. Our dedicated sales team are here to help and they can be reached by calling 01283 512111 or by using the handy online chat tool.
Specifications & Downloads
| Height | 2.0m [Installed] |
| Width | 3.0m |
| Material | Timber [Incised and Pressure Treated] |
| Colour | Tanalised UC4 [Pale Green] |
| Weight | 180kg |
| Ground Fixing | Dig In |
| Manufacturing Standards | BS 8417 [Timber Treatment] |
| Manufacturing Standards | BS EN 1793 Road Traffic Noise Reducing Devices |
| Manufacturing Standards | Tested and Complies to BS EN 1794-1 and BS EN 1794-2 |
| Manufacturing Standards | Design in accordance with specification for Highways Works Clause 2504. Treatment to Sector Scheme 4 |
| Density | Average Density 30.7kg/m² [Excluding Posts] |
What's Included
| Name | Quantity |
|---|---|
| Acoustic Tongue & Groove Boards [3.0m x 150mm x 38mm] | 16 |
| Gravel Board [HCD Timber, 3.0m x 150mm x 38mm] | 1 |
| Capping Rail [3.0m x 125mm x 38mm] | 1 |
| Counter Rail [3.0m x 75mm x 38mm] | 2 |
| Cover Strip [2.0m x 125mm x 38mm] | 1 |
| Centre Strip [2.0m x 75mm x 38mm] | 2 |
