2.0m High 'W' Section Powder Coated Palisade Security Fencing Kit
Green Powder Coated Triple Pointed Palisade
Product Description
2.0m High 'W' Section Powder Coated Palisade Security Fencing Kit
Manufactured from cold rolled steel, our 2.0m high Palisade fencing is designed to provide a permanent medium level of security. Designed for both soft ground and hard ground areas, this Palisade can be used in a number of settings, including industrial or commercial properties that require security protection.
Please note that our Palisade range does not come pre-assembled, and the components will need to be assembled on-site. For more information, please read our installation guide.
Key Features
- Manufactured from Cold Rolled Steel
- Pale Design is an excellent theft deterrent.
- Intimidating appearance
- Anti-tamper fixings
- Compliant to BS EN ISO 1461:2009
- Made in the UK
What makes our Palisade a medium level security fencing?
Our Palisade fencing is designed to create a secure and robust perimeter around an area that requires strong security fencing. This security fencing has a number of different security features which makes the fencing difficult to break into or climb over. All the pales have a ‘W’ section in their design which makes it incredibly difficult to grip onto.
Our Palisade fencing is available in three different pales types. Our triple pointed pales are the most secure, as the pales splits into three points. These spikes can catch on to clothing and make it very difficult to climb over. Our single pointed pales are a single point which make it very difficult to grip and use to climb over. Lastly, our round and notched pales are rounded at the top.
All our kits are equipped with a top and bottom rail. Our top rail is fitted with small spikes to prevent people from using the top bar to climb over. The bolts used are called snap off bolts and once fitted in place then can snap off to create a smooth anti-tamper finish.
If the intimidating appearance and spikes are not enough to put intruders off, then we do additional security features that can be added to the palisade fencing including razor wire, barbed wire and rotating spikes.
Where Can Palisade Fencing be used?
Our 2.0m High 'W' Section Palisade Security Fencing Kit are most popular in locations such as
- Industrial sites
- Schools
- Businesses that have large amounts of stock
- Commercial establishments
- Water treatment plants and power stations
- Bus and railway stations
- General fencing for establishing boundaries
What is included in 2.0m High 'W' Section Palisade Security Fencing Kit?
Our 2.0m High 'W' Section Palisade Security Fencing Kit contains the following items:
- 1x Palisade fencing Post (Dig In or Bolt Down Available)
- 17 x 'W' Section Palisade Fencing Pales (Triple Pointed, Single Point and Round & Notched available)
- 1 x Palisade Fencing Top Rail
- 1 x Palisade Fencing Bottom Rail
- 2 x Palisade Fencing Fishplates
- 4 x M12 x 30mm Bolts & Shear Nuts
- 34 x M8 x 25mm Bolts & Shear Nuts
Powder Coating finishes available
Our Palisade fencing is available in a galvanised finish or a powder coating finish. Our standard colours include Green, Blue, Black, Red, Grey and Brown. If you have another colour in mind, then please contact us as we do offer a custom powder coating service. Powder coating your fencing not only makes it more visually appealing, but it also offers an additional layer of protection against weathering and general wear and tear. If the powder coating finish was damaged or vandalised, then we offer a touch up spray which can easily cover the damage.
What ground types can Palisade fencing be installed on?
We have two types of posts designed for soft ground or hard ground installation. Dig in posts are designed for soft ground types where a hole can be dug into. Once the hole is dug, the posts can be placed inside and secured in place with our fast-setting post mix.
Bolt down posts are designed for hard ground areas such as concrete. Each bolt down posts is equipped with a 200x200mm base plate with 4 pre-drilled holes. Ground anchors are drilled to secure the post to the ground. We have standard ground anchors available or our resin ground anchors.
Post mix cement and ground anchor bolts are not included within this kit, but can be ordered separately if needed.
Installation requirements vary based on ground suitability. Installation guides are given as a recommendation only and show the maximum requirements for post holes for dig in systems as well as standard bolt holes for bolt down systems. Please refer to your installer for suitable installation requirements for your site and fence style.
Compatible accessories and gates
Our palisade accessories and gates are the perfect addition to your palisade fencing system. Our corner kits can be used to change our standard posts into a corner post. If your fencing does not join back on itself, you will need an additional end post to end the fencing system.
Contact Us
If you require more information about any products, please get in touch with the team by calling 01283 512 111, emailing sales@firstfence.co.uk, or using our online chat facility.
Specifications & Downloads
| Height | 2000mm [Installed Height] |
| Total Post Length | [Dig In: 2600mm] [Bolt Down: 2000mm] |
| Width | 2750mm [Post Centre to Post Centre] |
| Weight | [Per Bay: 64.34kg] [Per Metre: 23.4kg] |
| Post Types | Dig In, Bolt Down |
| Material | Galvanised Steel |
| Finish | Galvanised / Polyester Powder Coated (PPC) |
| PPC Colours | Green, Black, Blue, Red, Grey, Yellow |
| Compliant To | BS EN ISO 1461:2009 |
| Pale Types | Triple Pointed, Round & Notched, Single Point |
| Pale Height | 1950mm |
What's Included
| Name | Quantity |
|---|---|
| Palisade Fencing Post | 1 |
| 'W' Section Palisade Fencing Pales | 17 |
| Palisade Fencing Top Rail | 1 |
| Palisade Fencing Bottom Rail | 1 |
| Palisade Fencing Fishplates | 2 |
| Palisade Fencing M12 Bolts | 4 |
| Palisade Fencing M8 Bolts | 34 |
