How to Use the Locinox DRILLFIX Drilling Jig
Step-by-Step Installation & Product Overview
Learn how to use the Locinox DRILLFIX drilling jig for fast, precise installation of surface-mounted Locinox locks and keeps on metal swing gates. Available to order today from First Fence, this versatile tool kit guarantees exact hole alignment every time without measuring errors.
✨ Key Features
Universal Alignment: Works seamlessly with surface-mounted Locinox locks and keeps on any gate profile.
Precision Drilling: Eliminates measuring mistakes by providing exact hole placement for lock bodies, spindles, and keeps.
Complete Tool Set: Supplied in a heavy-duty case featuring robust jig components and drill guide bushings.
Time-Saving Solution: Drastically speeds up gate hardware installation for fencing contractors and installers.
🛠️ Quick Guide
Position Jig: Mark your desired handle height and clamp the DRILLFIX jig onto the gate leaf profile.
Drill Lock Holes: Drill through guided bushings using 3/8", 5/8", and 11/16" drill bits for lock mounting and spindles.
Fit Lock: Mount the Locinox surface-mounted lock and secure using Quick-Fix expanders.
Align & Drill Keep: Transfer the height line to the gate post, clamp the DRILLFIX jig, drill keep holes, and secure the keep.
🧰 Tools & Accessories Used
Locinox DRILLFIX jig set & protective storage case
Cordless power drill
3/8", 5/8", and 11/16" drill bits
Hex key / Allen key
