2.4m High x 1.2m Wide EnviroRail® Bow Top Single Leaf Gate Kit
Product Description
2.4m High x 1.2m Wide EnviroRail® Bow Top Single Leaf Gate Kit
Introducing the EnviroRail® Bow Top Gate collection by First Fence, a versatile addition designed to complement the aesthetic of the EnviroRail® Bow Top Railing series. These gates and railing panel kits within the EnviroRail® range not only serve a functional purpose but also boast exquisite visual appeal. Available in a spectrum of colours, with options for a single or double leaf, they are adaptable in width and height to accommodate various needs.
These Bow Top railings and gates enhance the charm of gardens, parks, schools, and residential areas, characterised by their distinctive curved top line that seamlessly integrates with diverse architectural styles. Beyond their elegance, these gates prioritise safety, featuring smooth, edge-free bowed tops that significantly reduce the risk of injuries and unauthorised access, ensuring clear visibility into enclosed spaces.
Features and Benefits
What sets the EnviroRail® Bow Top gate apart is its innovative manufacturing process. Utilising a low-weld technique, this eco-conscious system surpasses similar products available in the market. Laser-cut, custom-made pre-galvanised components form robust pressed connections during assembly, reducing energy-intensive welding requirements. If you are concerned about manufacturing impact, this is the product for you.
Constructed from high-quality pre-galvanised steel meeting BS 10346 standards and fortified with polyester powder coating in a wide range of standard or non-standard RAL colours, these gates are built to endure diverse weather conditions, making them ideal for outdoor use. Properly installed, they ensure years of reliable function with little maintenance required.
Each EnviroRail® kit is comprised of hollow tubular sections. These hollow tubes provide an incredibly high level of strength whilst helping to keep the weight to a minimum, making handling, transport and installation much easier. Each EnviroRail gate is fitted with a UniSlide kit, providing a secure and efficient sliding system for ease of use. The Single Leaf Kit contains a retainer plate and guide plate for alignment, a durable slider with an handle set and fixings.
Their versatility shines through hassle-free installation, thanks to a modular, lightweight design and adaptable handedness that eliminate constraints associated with fixed left or right-hand leaf orientations. Each gate arrives pre-drilled, streamlining the hinge and drop bolt installation process, with included plastic hole plugs for the unused holes. Customers can opt for additional locking drop bolts.
Safety is prioritised with a comprehensive gate kit including an EnviroRail® gate leaf, hinge, catch post, and three adjustable gate eyes in compliance with BS 12604 guidelines. Multiple hinges prevent gate leaf failure, ensuring safety and averting potential injuries or damage. Additionally, fully welded gate hooks provide an added layer of security. Each EnviroRail gate is fitted with a UniSlide kit, providing a secure and efficient sliding system for ease of use. The Single Leaf Kit contains a retainer plate and guide plate for alignment, a durable slider with an handle set and fixings.
Offering various widths and heights, this gate kit provides dig-in and bolt-down options catering to diverse installation needs. The dig-in option suits softer ground and requires Post Mix for a sturdy installation, while the bolt-down option is ideal for harder ground, secured using four M16 x 125mm anchor bolts.
This gate kit is compatible with our security locks and when installed correctly will give up to 30mm of adjustment from the catch post. The gates have 50mm ground clearance.
Apart from the Bow Top Gate collection, First Fence offers an extensive line-up including EnviroRail® Railings and Estate Railings and Gates, providing customers with a broad range of high-quality fencing solutions.
Get in touch!
If you have any questions about this product range or need assistance with your order, give our sales team a call and they will be happy to help you find the perfect fencing solution. The team can be contacted by calling 01283 512111 or by using the online chat tool.
Specifications & Downloads
| Height | 2400mm [Installed] |
| Access Width | 1200mm |
| Total Post Length | 2400mm [Bolt Down], 3100mm [Dig In] |
| Box Sections of Posts | 80x80mm |
| Box Section of Gate Leaf | 50x50mm |
| Rail Style | Bow Top - Hollow Tubular |
| Post Type | Dig In, Bolt Down |
| Gate Hanging Side | Universally Handed |
| Material | Pre-Galvanised Steel to BS EN 10346 |
| Finish | Polyester Powder Coated |
| PPC Colours | Green, Black, Blue, Red, Grey or Yellow |
What's Included
| Name | Quantity |
|---|---|
| Envirorail® Sliding Gate Leaf | 1 |
| Catch Gate Post | 1 |
| Hinge Gate Post | 1 |
| Adjustable Gate Eyes | 3 |
| Ribbed Inserts for Gate Frame | 2 |
| Ribbed Inserts for Posts | 2 |
| UniSlide Slider Kit | 1 |
Specifications & Downloads
| Height | 2400mm [Installed] |
| Access Width | 1200mm |
| Total Post Length | 2400mm [Bolt Down], 3100mm [Dig In] |
| Box Sections of Posts | 80x80mm |
| Box Section of Gate Leaf | 50x50mm |
| Rail Style | Bow Top - Hollow Tubular |
| Post Type | Dig In, Bolt Down |
| Gate Hanging Side | Universally Handed |
| Material | Pre-Galvanised Steel to BS EN 10346 |
| Finish | Polyester Powder Coated |
| PPC Colours | Green, Black, Blue, Red, Grey or Yellow |
What's Included
| Name | Quantity |
|---|---|
| Envirorail® Sliding Gate Leaf | 1 |
| Catch Gate Post | 1 |
| Hinge Gate Post | 1 |
| Adjustable Gate Eyes | 3 |
| Ribbed Inserts for Gate Frame | 2 |
| Ribbed Inserts for Posts | 2 |
| UniSlide Slider Kit | 1 |
