EchoGroove Lite 2.0m x 1.8m Wide UC4 Reflective Timber Acoustic Panel
EchoGroove Lite Timber Panel with Timber Posts. This is a pre-assembled panel.
Product Description
EchoGroove Lite 2.0m x 1.8m Wide UC4 Reflective Timber Acoustic Panel
The EchoGroove Lite Acoustic Panel is a durable timber acoustic barrier designed to reduce unwanted noise while providing a natural, attractive finish. Supplied pre-assembled, the solid interlocking pine panels offer a dense, gap-free barrier for effective sound control.
The panels can be installed with timber posts, slotted concrete posts or steel DuraPosts®, making them suitable for a range of sites, including uneven and sloping ground.
EchoGroove Lite is part of First Fence's range of timber acoustic fencing.
Key Features
- Pre-assembled panels: Solid, interlocking timber boards create a dense, gap-free acoustic barrier and make installation quicker.
- UC4 pressure-treated timber: TANALITH® treatment helps protect against rot, fungal decay and insect attack, making the timber suitable for ground contact.
- Integrated gravel board: Helps protect the main panel from ground moisture and decay.
- Versatile post compatibility: Suitable for timber, concrete and steel DuraPost® systems.
- Standard 1.829m width: 6ft-wide panels are available in a range of heights for straightforward project planning.
- Surface-incised timber: Ground-contact components are incised to improve preservative penetration and long-term protection.
Benefits
- Effective Noise Reduction: The high-mass, solid construction reflects sound waves to help reduce noise from traffic, commercial activity and neighbouring properties. Tested to BS EN 1793, EchoGroove Lite achieves a 25dB noise reduction and B3 rating – the highest rating possible.
- Quick & Easy Installation: Pre-assembled panels are faster to install than traditional fencing made from individual boards, helping to save time and reduce labour costs.
- Durable & Long-Lasting: The robust construction and UC4 pressure treatment provide long-term protection and a desired service life of up to 15 years when correctly installed.
- Low Maintenance: The preservative treatment provides long-term protection without the need for regular re-treatment. Panels can also be finished with a breathable wood stain or paint.
- Natural Appearance: The solid timber construction and grooved design provide a traditional, attractive finish that complements residential and commercial properties. Decorative trellis tops can also be added for further customisation.
Applications
EchoGroove Lite is suitable for a wide range of locations where noise reduction and privacy are important, including:
- Railway lines: Helps reduce noise from passing trains.
- Gardens and residential properties: Creates a quieter, more private outdoor space.
- Domestic equipment: Screens noise from air conditioning units, generators and heat pumps.
- Pubs, restaurants and hotels: Helps manage noise from outdoor seating areas.
- Retail and logistics sites: Screens noise from car parks, loading bays and delivery vehicles.
- Schools and nurseries: Helps reduce external traffic noise and contain noise within the boundary.
- Industrial and utility sites: Helps shield nearby properties from generators, substations and light industrial activity.
Installation
EchoGroove Lite panels are supplied pre-assembled for straightforward installation with timber, concrete or DuraPost® posts.
This is a dig-in system, so the posts must be concreted into the ground. A site assessment is recommended to determine the correct product specifications and installation method for your project.
Before installation, clear vegetation from the fence line and ensure the posts are installed in well-drained ground away from standing water.
For site-specific applications, a structural engineer should assess wind loading suitability before installation.
The manufacturer promotes a 15-year desired service life when the system is correctly installed.
The panels can be painted or finished with a breathable wood stain.
For heavier-duty acoustic requirements, First Fence also supplies EchoGroove, EchoReflect and EchoAbsorb systems in a range of widths and heights.
We also offer a range of Sound Absorption Barriers and accessories.
Contact Us
Need help choosing the right acoustic fencing for your project? Our friendly sales team is here to help. Call 01283 512111, email sales@firstfence.co.uk, or contact us through our online chat.
Specifications & Downloads
| Height | 2.0m |
| Width | 1.829m |
| Material | Timber [Incised and Pressure Treated] |
| Colour | Tanalised UC4 [Pale Green] |
| Weight | 49.32kg |
| Ground Fixing | Dig In |
| Manufacturing Standards | BS 8417 [Timber Treatment] |
| Manufacturing Standards | BS EN 1793 Road Traffic Noise Reducing Devices |
| Manufacturing Standards | Tested and Complies to BS EN 1794-1 and BS EN 1794-2 |
| Manufacturing Standards | Design in accordance with specification for Highways Works Clause 2504. Treatment to Sector Scheme 4 |
What's Included
| Name | Quantity |
|---|---|
| 2.0m High x 1.829m Wide EchoGroove Lite Acoustic Panel | 1 |
Specifications & Downloads
| Height | 2.0m |
| Width | 1.829m |
| Material | Timber [Incised and Pressure Treated] |
| Colour | Tanalised UC4 [Pale Green] |
| Weight | 49.32kg |
| Ground Fixing | Dig In |
| Manufacturing Standards | BS 8417 [Timber Treatment] |
| Manufacturing Standards | BS EN 1793 Road Traffic Noise Reducing Devices |
| Manufacturing Standards | Tested and Complies to BS EN 1794-1 and BS EN 1794-2 |
| Manufacturing Standards | Design in accordance with specification for Highways Works Clause 2504. Treatment to Sector Scheme 4 |
What's Included
| Name | Quantity |
|---|---|
| 2.0m High x 1.829m Wide EchoGroove Lite Acoustic Panel | 1 |
