Apollo® 3.0m High x 1.0m Wide 358 Prison Mesh Single Leaf Gate Kit
Product Description
Apollo® 3.0m High x 1.0m Wide 358 Prison Mesh Single Leaf Gate Kit
The Apollo® 3.0m High x 1.0m Wide Single Leaf Gate Kit delivers a high-security access point in a compact footprint, making it perfect for controlled pedestrian entry in environments where space is limited. Designed to work seamlessly alongside 3.0m high mesh fencing systems, this gate is well-suited to a variety of applications across commercial, educational, and public infrastructure projects.
Engineered with strength, security, and visibility in mind, this gate features a solid steel frame and high-security 358 mesh to protect against intrusion, trespassing, and vandalism.
Benefits and Features
Durable Steel Frame with Powder Coated Finish
Constructed from premium steel and finished with clean mitred corners, this gate is built for structural integrity and long-term durability. It’s coated in a weather-resistant Polyester Powder Coating (PPC), which is available in a range of RAL colours to suit your site’s needs, whether you prefer bold visibility or discreet integration with surrounding fencing.
Modular Design
The gate is designed to be universally handed, allowing for installation to swing open from either side. A manual sliding latch is provided for quick and secure operation, with the option to upgrade to a Gatemaster locking system at a later stage if desired.
Secure 358 Mesh Infill
This gate includes 358 mesh, a dense wire panel configuration renowned for its difficulty in climbing, and difficulty in cutting properties. The tight aperture resists tampering while maintaining high levels of visibility, ideal for surveillance points, monitored entryways, and sensitive locations.
Increase Safety with a Gate Restrainer
Pre-drilled to accept an optional gate restrainer (available separately), this gate can be adapted to meet BS 12604 standards. The tether system helps prevent the gate from falling beyond a safe angle in the event of hinge failure, reducing the risk of accidents and improving safety on site.
Installation Options for All Ground Types
Two post types are available depending on your surface conditions:
- Bolt Down Posts: Suitable for concrete or hard ground (requires 4 x M16 x 125mm anchor bolts per post).
- Dig In Posts: Ideal for soft ground or soil; posts are installed with concrete post mix for a firm, lasting hold.
Designed for Narrow Pedestrian Entry Points
With a clear width of 1.0m, this gate is perfect for foot traffic, staff entrances, or restricted access zones. It’s an ideal choice for schools, utility sites, business parks, and storage areas where space is tight but security is critical.
What’s Included in the Kit
- 1 x 3.0m High x 1.0m Wide Gate Leaf with 358 Mesh Infill
- 1 x Hinge Post
- 1 x Catch Post
- 1 x Lockable Sliding Latch Kit
- 1 x Plate Kit
- 2 x Adjustable Gate Eyes
- Plastic Post Caps
Compatible Mesh Fencing Systems
This gate is fully compatible with a wide range of mesh fencing styles, including V Mesh, 358 mesh and Twin Wire 868 and 656 mesh fencing systems
Contact Us
Our friendly and professional sales team are here to help with any questions you may have regarding the Apollo gate range or any of our other fencing and security systems. We can be reached by phone on 01283 512 111, by email at sales@firstfence.co.uk or through our online live chat system.
Specifications & Downloads
| Height Above Ground | 3000mm |
| Access Width | 1000mm |
| Total Width | 1290mm |
| Hinge Post Size | 80mm x 80mm |
| Hinge Gap | 100mm |
| Leaf Gap | 30mm |
| Gate Hanging Side | Universally Handed |
| Post Type | Square Hollow Section |
| Gate Type | Pedestrian Gate |
| Material | Pre-Galvanised Steel |
| Finish | Powder Coated |
| PPC Colours | Green & Black as Standard, Others Available On Request |
| Compliant To | Pre-Galvanised Steel to BS EN 10346 / Powder Coated to BS 13438 |
What's Included
| Name | Quantity |
|---|---|
| Apollo 358 Mesh Gate Leaf | 1 |
| Catch Gate Post | 1 |
| Hinge Gate Post | 1 |
| Adjustable Gate Eyes | 2 |
| Ribbed Inserts for Posts | 2 |
| Unislide Single Slider Padlockable Gate Kit | 1 |
| Apollo Plate Kit | 1 |
| Auto Locking Drop Bolt | 1 |
| 3.0m Clamp Bar [30x5mm @ 3030mm] | 2 |
| M8 x 90mm Nuts and Bolts | 22 |
