Apollo® 3.0m High x 1.5m Wide 358 Prison Mesh Single Leaf Gate Kit
Product Description
Apollo® 3.0m High x 1.5m Wide 358 Prison Mesh Single Leaf Gate Kit
The Apollo® 3.0m High x 1.5m Wide Single Leaf Gate Kit offers a compact yet highly secure entry point, ideal for pedestrian access or restricted vehicle use. Designed to integrate with 3.0m high mesh fencing systems, this gate combines durability, visibility, and security, making it an excellent choice for both public and private sector sites.
With a robust steel structure and 358 mesh infill, it delivers a robust solution to prevent unauthorised entry, tampering, and vandalism.
Key Features and Advantages
Robust Steel Construction with Long-Lasting Protection
Manufactured using premium-grade steel and precision-welded mitred corners, this gate offers lasting structural strength and a clean, professional appearance. It's finished with a tough Polyester Powder Coating (PPC), available in various RAL colours, providing resistance to weather, corrosion, and general wear.
Universal Modular Design
This gate is designed to be universally handed, meaning it can be installed to open left or right, depending on the layout of your site. A manual sliding latch is included for immediate security, with simple upgrade options available to fit Gatemaster lock systems as needed.
High-Security 358 Mesh Infill
The 358 mesh panel, often referred to as prison mesh, features a dense wire pattern that’s nearly impossible to climb or cut. Its tight aperture deters intruders while still allowing clear lines of sight for CCTV and monitoring systems.
Add a Gate Restrainer for Additional Safety
Pre-drilled holes allow for the installation of a gate restraining tether (sold separately). These tethers help ensure compliance with BS 12604 safety standards by preventing the gate leaf from falling more than 300mm if a hinge were to fail, reducing the risk of injury or property damage.
Post Options to Suit Any Installation Surface
Choose from two post types depending on your surface conditions:
- Bolt Down Posts: Ideal for installation on concrete or tarmac; requires 4 x M16 x 125mm anchor bolts per post.
- Dig In Posts: Designed for soil or softer ground types; posts are set using post mix for a secure hold.
Drop Bolt for Enhanced Control
A heavy-duty drop bolt is included with the gate, allowing it to be locked open during high-traffic periods or secured shut for added protection.
Ideal for Pedestrian & Light-Duty Access
With a 1.5m clear width, this gate is suited for controlled pedestrian access, bicycles, or small equipment. It’s perfect for environments like schools, recreational facilities, depots, or secure walkways within industrial and commercial sites.
What’s Included in Your Kit
- 1 x 3.0m High x 1.5m Wide Gate Leaf with 358 Mesh Infill
- 1 x Hinge Post
- 1 x Catch Post
- 1 x Lockable Sliding Latch Kit
- 1 x Plate Kit
- 2 x Adjustable Gate Eyes
- 1 x Locking Drop Bolt
- Plastic Post Caps for a Neat Finish
Mesh Fence Compatibility
Fully compatible with a wide range of mesh fencing systems, including V mesh, twin wire 868, and 656 mesh systems.
Contact Us
If you have any questions about our range of Apollo security gates, please don't hesitate to get in touch. We can be reached by phone on 01283 512 111, by email at sales@firstfence.co.uk or through our online live chat system.
Specifications & Downloads
| Height Above Ground | 3000mm |
| Access Width | 1500mm |
| Total Width | 1830mm |
| Hinge Post Size | 100mm x 100mm |
| Hinge Gap | 100mm |
| Leaf Gap | 30mm |
| Gate Hanging Side | Universally Handed |
| Post Type | Square Hollow Section |
| Gate Type | Single Leaf |
| Material | Pre-Galvanised Steel |
| Finish | Powder Coated |
| PPC Colours | Green & Black as Standard, Others Available On Request |
| Compliant To | Pre-Galvanised Steel to BS EN 10346 / Powder Coated to BS 13438 |
What's Included
| Name | Quantity |
|---|---|
| Apollo 358 Mesh Gate Leaf | 1 |
| Catch Gate Post | 1 |
| Hinge Gate Post | 1 |
| Adjustable Gate Eyes | 2 |
| Ribbed Inserts for Posts | 2 |
| Unislide Single Slider Padlockable Gate Kit | 1 |
| Apollo Plate Kit | 1 |
| Auto Locking Drop Bolt | 1 |
| 3.0m Clamp Bar [30x5mm @ 3030mm] | 2 |
| M8 x 90mm Nuts and Bolts | 22 |
Specifications & Downloads
| Height Above Ground | 3000mm |
| Access Width | 1500mm |
| Total Width | 1830mm |
| Hinge Post Size | 100mm x 100mm |
| Hinge Gap | 100mm |
| Leaf Gap | 30mm |
| Gate Hanging Side | Universally Handed |
| Post Type | Square Hollow Section |
| Gate Type | Single Leaf |
| Material | Pre-Galvanised Steel |
| Finish | Powder Coated |
| PPC Colours | Green & Black as Standard, Others Available On Request |
| Compliant To | Pre-Galvanised Steel to BS EN 10346 / Powder Coated to BS 13438 |
What's Included
| Name | Quantity |
|---|---|
| Apollo 358 Mesh Gate Leaf | 1 |
| Catch Gate Post | 1 |
| Hinge Gate Post | 1 |
| Adjustable Gate Eyes | 2 |
| Ribbed Inserts for Posts | 2 |
| Unislide Single Slider Padlockable Gate Kit | 1 |
| Apollo Plate Kit | 1 |
| Auto Locking Drop Bolt | 1 |
| 3.0m Clamp Bar [30x5mm @ 3030mm] | 2 |
| M8 x 90mm Nuts and Bolts | 22 |
