Apollo® 2.0m High x 2.5m Wide 358 Prison Mesh Single Leaf Gate Kit
Product Description
Apollo® 2.0m High x 2.5m Wide 358 Prison Mesh Pedestrian Gate Kit
The Apollo® 2.0m High x 2.5m Wide 358 Prison Mesh Pedestrian Gate Kit is a high-security, heavy-duty access solution designed for sites that require robust pedestrian entry control. Its extra-wide 2.5m opening makes it ideal for accommodating high footfall, equipment access, or mobility-friendly entry, while its 358 prison mesh construction ensures uncompromising protection. Built from pre-galvanised steel and finished with a durable Polyester Powder Coating, this gate is engineered to perform in demanding environments for years to come.
Key Features
- Strong 358 Prison Mesh: Welded intersections create a rigid, tamper-resistant barrier that’s extremely difficult to climb or cut.
- Durable Finish: Polyester Powder Coating offers superior corrosion, UV, and weather resistance.
- Modular Design: Supplied with a sliding latch but compatible with keyed or digital locking systems.
- Universal Hanging: Can be installed to open left or right.
- Compatibility: Works seamlessly with standard mesh fencing including 358, 358D, 868, 656, and other mesh systems.
- Two Adjustable Hinges: For smooth, secure operation and easy alignment during installation.
- Pre-Drilled for Gate Restrainer: Ready for fitting a safety tether (sold separately) to comply with BS EN 12604 safety standards.
Applications
This Apollo® gate is ideal for environments that demand both strength and clear visibility, such as industrial estates, commercial premises, transport hubs, schools, and high-security sites like correctional facilities or airports. The 2.5m width allows for increased accessibility, making it suitable for pedestrian traffic, maintenance equipment, or goods movement without compromising security. The mesh design supports surveillance by maintaining sightlines while preventing unauthorised access.
Post Types
To suit different site conditions, the Apollo® 2.0m High x 2.5m Wide 358 Prison Mesh Pedestrian Gate Kit is available with two post options:
- Bolt-Down Posts: For solid surfaces like concrete, ground anchors are used to secure the posts.
- Dig-In Posts: For softer ground types such as soil or grass, secured with post mix.
Contact Us
If you do have any questions, please do not hesitate to speak to one of our sales team by calling 01283 512 111 or by using the online chat facility, and they will be happy to help you.
Specifications & Downloads
| Height Above Ground | 2000mm (above ground) |
| Access Width | 2500mm |
| Total Width | 2810mm |
| Hinge Post Size | 100mm x 100mm |
| Hinge Gap | 100mm |
| Leaf Gap | 30mm |
| Gate Hanging Side | Universally Handed |
| Mesh Type | 358 Prison Mesh |
| Post Type | Square Hollow Section |
| Gate Type | Single Leaf |
| Material | Pre-Galvanised Steel |
| Finish | Powder Coated |
| PPC Colours | Green & Black as Standard, Others Available On Request |
| Compliant To | Pre-Galvanised Steel to BS EN 10346 / Powder Coated to BS 13438 |
What's Included
| Name | Quantity |
|---|---|
| Apollo 358 Mesh Gate Leaf | 1 |
| Catch Gate Post | 1 |
| Hinge Gate Post | 1 |
| Adjustable Gate Eyes | 2 |
| Ribbed Inserts for Posts | 2 |
| Unislide Single Slider Padlockable Gate Kit | 1 |
| Apollo Plate Kit | 1 |
| Auto Locking Drop Bolt | 1 |
| 2.0m Clamp Bar [30x5mm @ 2030mm] | 2 |
| M8 x 100mm Nuts and Bolts | 16 |
