Apollo® 2.0m High x 1.5m Wide 358 Prison Mesh Single Leaf Gate Kit
Product Description
Apollo® 2.0m High x 1.5m Wide 358 Prison Mesh Pedestrian Gate Kit
The Apollo® 2.0m High x 1.5m Wide 358 Prison Mesh Gate Kit is the premier solution for controlling pedestrian access in high-security environments. Engineered with precision and durability in mind, this complete gate system provides a formidable entry point, seamlessly integrating the renowned strength of 358 Prison Mesh with superior construction. It offers an ideal balance of robust security, clear visibility for surveillance, and long-term, reliable performance for any perimeter.
This gate is designed to integrate perfectly with 358 Prison Mesh and 358D fencing systems for a uniform, high-security perimeter. Its versatile design also makes it compatible with other popular fencing styles, including 868 Twin Mesh and profiled V Mesh, offering greater flexibility in site design.
Key Apollo® Features
High Security 358 Mesh: The gate features a 358 Prison Mesh infill, one of the most secure options available. Constructed from prison mesh, makes it nearly impossible for intruders to gain a foothold or finger-hold, effectively preventing climbing attempts while allowing excellent visibility for CCTV monitoring.
Dual-Layer Weather Protection: The gate’s resilience begins with its high-quality, pre-galvanised steel frame, which provides foundational protection against rust. A durable polyester powder coating is then applied, adding a sleek, professional finish and a second, tough barrier against corrosion and environmental wear.
Safe and Professional Construction: All corners of the gate frame are mitred, creating a clean, professional appearance and eliminating sharp edges. The gate is supported by two heavy-duty adjustable hinges. Our Apollo® gates have a predrilled hole where a gate restrainer can be added to make the gate compliant with BS EN 12604 safety standards.
Advanced, Upgradable Locking: Security is handled by a versatile sliding latch plate. This can be secured with a standard padlock or easily upgraded to a range of Gatemaster locking systems, including digital keypads and key-operated locks, without requiring any modification to the gate.
Flexible Installation: The Apollo® gate system is designed for complete flexibility on-site. It features universal handing, allowing it to be configured for either left-hand or right-hand opening during installation to suit any site layout.
Applications
The strength and security features of this 1.5m wide pedestrian gate make it suitable for a variety of demanding applications. The 2.0m height provides a high security barrier for locations such as:
- Commercial properties and industrial estates
- Schools, colleges, and university campuses
- Correctional facilities and police stations
- Airports and transport hubs
- Data centres and utility compounds
Installation & Compatibility
The Apollo® gate is designed for easy installation on various ground types. Dig-In Posts are ideal for softer terrains like soil and grass, while Bolt-Down Posts provide a secure fit on existing concrete surfaces.
For a seamless perimeter, this gate integrates perfectly with 358 Prison Mesh fencing systems. Please note that additional M8 x 40mm bolts and mesh fencing clips may be required to connect the gate posts to adjoining fence panels.
Get in Touch
If you have any questions or need assistance, our dedicated sales team is available to help. Contact us at 01283 512 111 or use our online chat facility for immediate support. We are committed to providing high-quality security solutions tailored to your needs.
Specifications & Downloads
| Height Above Ground | 2000mm |
| Access Width | 1500mm |
| Total Width | 1790mm |
| Hinge Post Size | 80mm x 80mm |
| Hinge Gap | 100mm |
| Leaf Gap | 30mm |
| Universally Handed | Universally Handed |
| Mesh Type | 358 Prison Mesh |
| Post Type | Square Hollow Section |
| Gate Type | Pedestrian Gate |
| Material | Pre-Galvanised Steel |
| Finish | Powder Coated |
| PPC Colours | Green & Black as Standard, Others Available On Request |
| Compliant To | Pre-Galvanised Steel to BS EN 10346 / Powder Coated to BS 13438 |
What's Included
| Name | Quantity |
|---|---|
| Apollo 358 Mesh Gate Leaf | 1 |
| Catch Gate Post | 1 |
| Hinge Gate Post | 1 |
| Adjustable Gate Eyes | 2 |
| Ribbed Inserts for Posts | 2 |
| Unislide Single Slider Padlockable Gate Kit | 1 |
| Apollo Plate Kit | 1 |
| Auto Locking Drop Bolt | 1 |
| 2.0m Clamp Bar [30x5mm @ 2030mm] | 2 |
| M8 x 100mm Nuts and Bolts | 16 |
