FFL 95 Automated Mesh Cantilever Gate 3.5m - 5.5m Wide
Product Description
FFL 95 Automated Mesh Cantilever Gate 3.5m - 5.5m Wide
The FFL 95 Automated Mesh Cantilever Gate is a heavy-duty access solution designed to provide secure and reliable vehicle entry. Suitable for both commercial and residential properties, its cantilever design allows the gate to slide smoothly without a ground track, making it ideal for sites with limited space.
The FFL 95 features a built-in 24V gate motor, housed within the support post. This provides a clean, streamlined appearance while protecting the automation system from the elements.
The gate is fitted with 868 Twin Mesh infill, offering a strong and secure barrier with a modern appearance. The mesh is bolted to the gate frame for a durable finish.
Available in widths from 3.5m to 5.5m, the FFL 95 is offered in a range of heights and standard RAL colours. Custom colours are also available at an additional cost. Galvanised-only options can be discussed with our sales team.
The FFL 95 is also available as the FFL 130 (5.0m - 7.5m) and FFL 200 (8.0m - 12.0m), as well as a manual option.
All FFL Series manual and automated cantilever gates come with a 2-year manufacturer's warranty.
Features & Benefits
- Heavy-duty steel construction for strength and durability
- Built-in 24V motor housed within the support post
- 100% duty cycle for reliable frequent use
- Opening speed of up to 9m/min
- 868 Twin Mesh infill for enhanced security
- Mesh is bolted to the frame for a secure finish
- Cantilever design eliminates the need for a ground track
- Protective finish helps prevent rust and withstand harsh weather
- Safety sensors stop the gate if an obstruction is detected
- Advanced locking system for enhanced security
- Available in a range of RAL colours
- Plug-and-play system for straightforward installation
- Compatible with access control and smart technology
Optional Extras
Enhance your gate with a range of optional accessories, including:
- Anti-climb spikes (available on gates over 1.8m high)
- Reflective strips
- Loop detectors
- Intercoms
- Press-to-exit buttons
- Laser scanners
Run-Back Space Requirements
The FFL 95 requires sufficient space behind the gate to allow it to fully open. Make sure your site has enough run-back space and overall clearance before ordering.
FFL 95 Gate Width | Recommended Run-Back Space | Overall Space Required |
|---|---|---|
3500mm | 5200mm | 8700mm |
4000mm | 5900mm | 9900mm |
4500mm | 6600mm | 11100mm |
5000mm | 7100mm | 12100mm |
5500mm | 7800mm | 13300mm |
Contact Us
Not sure which gate or configuration is right for your site? Our sales team can help you choose the right solution. Call 01283 512111, email sales@firstfence.co.uk, or speak to us using our online chat.
Specifications & Downloads
| Width | 3.5, 4.0, 4.5, 5.0 or 5.5m [5.5m is not available as 2.2m Height] |
| Height | 1.0, 1.2, 1.5, 1.8, 2.0 or 2.2m |
| Size | Other Sizes Available - Call To Discuss |
| Lead Time | Starts From Drawings Sign Off |
| Material | Galvanised Steel |
| Duty Cycle | 100% Duty Cycle for Intensive Use |
| Finish | Polyester Powder Coated |
| Box Section of Main Gate Frame | 60 x 60mm |
| Infill Type | 868 Twin Mesh |
| Manufacturer Warranty | 2-Years |
| Standards | Automated Gate Safety to BS EN 12453 |
What's Included
| Name | Quantity |
|---|---|
| Gear Rack [Fitted] | 1 |
| Cantilever Carriages | 2 |
| Bolt Down End Catcher Post | 1 |
| Motor Cabinet & Rear Support Post | 1 |
| Top Support Roller System | 1 |
| Sliding Gate Motor (hidden in the post) | 1 |
| Flashing Light | 1 |
| Dual Height Photocells | 1 |
| Key-Operated Switch With Emergency Stop Button | 1 |
| Category 3 Safety Edges | 6 |
| Remote Control Transmitters/Fobs | 2 |
| Gate Mounted Safety Edge Transmission System | 1 |
| External RF Aerial | 1 |
| Ground Anchor Bolts | 12 |
| Run Back Support Roller | 1 |
