FFL 60P Semi-Automatic 358 Mesh Pedestrian Gate
Product Description
FFL 60P Semi-Automatic 358 Mesh Pedestrian Gate
Introducing First Fence's new range of semi-automatic pedestrian gates, a high-end choice for secure and stylish access control. Crafted with a dedication to quality and innovation, these gates provide reliable and convenient access for both residential and commercial properties.
First Fence's FFL 60P Semi-Automatic Pedestrian Gates feature a range of heights starting at 1.8m high up to 2.4m high. Select from a range of widths to get the perfect fit for your location.
The FFL 60P is a premium, semi-automatic pedestrian gate engineered for high-security environments where controlled access and aesthetic integration are paramount. Designed specifically to complement 358 "Prison Mesh" fencing systems, this gate provides a formidable physical barrier without sacrificing ease of use.
All our Semi-Automatic Pedestrian Gates are available with two locking options: a Locinox Maglock for Fail Open functionality and a Standard Locinox Lock with an electronic strike for a Fail Secure option. In the event of a power failure, the Fail Open option will release the maglock and allow free passage through the gate, whereas the Fail Secure option will remain locked and cannot be opened until power is activated again.
Whether securing a data centre, utility site, or school perimeter, the FFL 60P delivers a robust, "anti-climb" solution that stands up to the most demanding UK site requirements.
If you require a specific colour not listed or prefer a galvanised-only finish, please reach out to us to discuss your needs. Be aware that custom colours will incur an additional charge.
The FFL series of gates comes with a 2-year manufacturer's warranty.
Key Features and Benefits
- Anti-Climb 358 Mesh Infill: Features the industry-standard 76.2 mm x 12.7 mm mesh pattern. The apertures are too small for finger or toe holds, and the wire is incredibly difficult to cut with conventional tools.
- Semi-Automatic Operation: Equipped with a high-quality hydraulic closing mechanism. This ensures the gate returns to a secure, closed position automatically after use, eliminating the risk of gates being left ajar.
- Ease of Installation: Delivered with hardware mounting points pre-aligned for the Locinox gate closer and magnetic lock. (Drilling for gates narrower than 1100mm width may be required on site)
- Safety First: Equipped with adjustable closing speeds and soft-stop technology to prevent slamming and ensure pedestrian safety.
- Robust Framework: The gate leaf is housed in a heavy-duty box section frame, galvanised and powder-coated for maximum weather resistance and longevity.
- Reliable Integration: Compatible with virtually all 12V/24V DC access control systems.
Ideal Applications
The FFL 60P is the go-to solution for facilities requiring controlled entry points that match existing mesh fencing:
- Schools & Colleges: Safe, reliable access for students and staff.
- Commercial Business Parks: Professional aesthetics with high-level security.
- Sports Facilities: Durable enough to handle heavy use in public arenas.
- Industrial Sites: Integrated perimeter protection for restricted zones.
A selection of additional options is available to add to your gate order, such as anti-climb spikes.
If you require matching fencing, please speak to our sales team about the best options to match this range.
Contact Us
If you need additional information or assistance in selecting the right product, please get in touch, and one of our sales team members will be happy to guide you through your purchase. The team can be contacted by calling 01283 512111 or by using the online chat tool.
Specifications & Downloads
| Width (inside post to post) | 0.8m, 0.9m, 1.0m, 1.1m, 1.2m, 1.3m |
| Height (leaf height from ground level) | 1.8m, 1.9m, 2.0m, 2.1m, 2.2m, 2.3m, 2.4m |
| Size | Other Sizes Available - Call To Discuss |
| Lead Time | Starts From Drawings Sign Off |
| Material | Galvanised Steel to ISO 1461 |
| Finish | Polyester Powder Coated to BS EN 13438 |
| Box Section of Main Gate Frame | 60 x 40mm |
| Infill Type | 358 Mesh |
| Manufacturer Warranty | 2-Years |
| Bolt Down Post Hole Dimension | 100mm/120mm - 16mm / 160mm - 20mm |
What's Included
| Name | Quantity |
|---|---|
| 358 Mesh Gate | 1 |
| Hinges | 2 |
| 100mm Bolt Down Post | 2 |
| Locinox Hydraulic Closer | 1 |
| Locinox Maglock | 1 |
Specifications & Downloads
| Width (inside post to post) | 0.8m, 0.9m, 1.0m, 1.1m, 1.2m, 1.3m |
| Height (leaf height from ground level) | 1.8m, 1.9m, 2.0m, 2.1m, 2.2m, 2.3m, 2.4m |
| Size | Other Sizes Available - Call To Discuss |
| Lead Time | Starts From Drawings Sign Off |
| Material | Galvanised Steel to ISO 1461 |
| Finish | Polyester Powder Coated to BS EN 13438 |
| Box Section of Main Gate Frame | 60 x 40mm |
| Infill Type | 358 Mesh |
| Manufacturer Warranty | 2-Years |
| Bolt Down Post Hole Dimension | 100mm/120mm - 16mm / 160mm - 20mm |
What's Included
| Name | Quantity |
|---|---|
| 358 Mesh Gate | 1 |
| Hinges | 2 |
| 100mm Bolt Down Post | 2 |
| Locinox Hydraulic Closer | 1 |
| Locinox Maglock | 1 |
