2.0m High x 6.0m Wide EnviroRail® Bow Top Double Leaf Gate Kit
Slider and Drop Bolt Sold Separately
| Height | 2000mm [Installed] |
| Access Width | 6000mm |
| Total Post Length | 2000mm [Bolt Down], 2600mm [Dig In] |
| Box Sections of Posts | 100x100mm |
| Box Section of Gate Leaf | 50x50mm |
| Rail Style | Bow Top - Hollow Tubular |
| Post Type | Dig In, Bolt Down |
| Gate Hanging Side | Universally Handed |
| Material | Pre-Galvanised Steel |
| Finish | Pre-Galvanised Steel to BS EN 10346 |
| PPC Colours | Green, Black, Blue, Red, Grey or Yellow |
| Name | Quantity |
|---|---|
| Envirorail® Sliding Gate Leaf | 2 |
| Hinge Gate Post | 2 |
| Adjustable Gate Eyes | 6 |
| Ribbed Inserts for Gate Frame | 4 |
| Ribbed Inserts for Posts | 2 |
2.0m High x 6.0m Wide EnviroRail® Bow Top Double Leaf Gate Kit
Bow Top railing is an elegant and cost-effective solution designed to define boundaries in both public and private spaces, offering enduring charm and durability.
Introducing the EnviroRail® Bow Top Gate series by First Fence, a perfect complement to the corresponding railing system. Its gracefully curved top combines practicality and sophistication, creating a sturdy enclosure inspired by 19th-century aesthetics, ideal for diverse environments like parks, schools, commercial, and residential areas.
As part of the EnviroRail® series, First Fence proudly presents gate kits in single and double leaf options, featuring various polyester powder-coated colours. These gates are adaptable to different ground types, offering flexibility for bolt-down or dig-in installations, making them suitable for diverse surroundings.
Features and Benefits
The EnviroRail® Bow Top Double Leaf Gate Kit, measuring 2.0m tall and 6.0m wide, provides versatile access control for both pedestrians and vehicles. This is one of the largest, widest gates in the range and is ideal for a broad gate or driveway. Constructed from pre-galvanised steel and polyester powder-coated for utmost protection, this gate ensures a prolonged lifespan and resilience against wear and tear.
This gate kit's eco-friendly design reduces reliance on welding by employing custom-made, laser-cut components. It boasts modularity and a lightweight build for effortless installation, with pre-drilled holes for adjustable hinges and a drop bolt, conforming to BS 12604 safety standards for stability. In the event of hinge failure, the gate remains upright and secure, reducing the risk of injury or damage. This modularity allows for adjustability which fixed hardware doesn't offer.
Each EnviroRail® kit is comprised of hollow tubular sections. These hollow tubes provide an incredibly high level of strength whilst helping to keep the weight to a minimum, making handling, transport and installation much easier.
The EnviroRail® Double Gates offer a fully modular and relatively lightweight solution for securing a gate or driveway, ensuring easy installation for various hardware needs. Their universal handing allows on-site flexibility without fixed left or right-hand specifications. Each gate in the kit comes with pre-drilled holes for six adjustable hinges and a drop bolt, along with included plastic hole plugs to cover unused holes. An additional locking drop bolt option enhances security and is recommended for the double leaf gate.
The EnviroRail® Double Gates comprise two gate leaves, posts, and adjustable gate eyes, meeting safety standards for safety. This gate is compliant with BS 12604 guidelines to ensure stability; if even one hinge fails the gate will still remain secure. The hooks are fully welded to the gate post, presenting fixed axis hinges.
In addition to gate kits, First Fence offers Railings, Estate Railings, and Gates, providing security options with additional locking mechanisms.
