Apollo® 2.4m High x 3.5m Wide 358 Prison Mesh Single Leaf Gate Kit
Product Description
Apollo® 2.4m High x 3.0m Wide 358 Prison Mesh Single Leaf Gate Kit
Introducing the Apollo® 2.4 m × 3.0 m 358 Mesh Single‑Leaf Gate Kit, specially engineered to offer secure single-lane vehicle access while maintaining maximum perimeter protection. Its design integrates flawlessly into 358 Prison Mesh systems, ensuring consistent form and function.
Impenetrable Mesh Design
Crafted from 358 Prison Mesh, known for its narrow apertures and durable wire, this mesh is both anti-climb and cut-resistant, yet delivers excellent visibility for surveillance. Its dense, welded-wire pattern makes it extremely challenging to scale or breach.
Flexible Installation Options
Tailored for diverse ground conditions:
- Bolt‑Down Posts for solid surfaces such as concrete
- Dig‑In Posts (set with Postfix cement) for softer terrain
Please note that post mix and anchor bolts are not included and should be purchased separately, depending on your installation type.
Robust Wire Mesh Design
This gate showcases the trusted Apollo 358 wire mesh, expertly crafted from vertical and horizontal steel wires. The welded mesh pattern is exceptionally tight, designed to resist cutting or deformation, while still offering clear visibility for CCTV and monitoring. That anti‑climb layout makes this mesh the go-to choice for high-security environments.
Built to Last: High-Quality Construction
Fabricated from pre‑galvanised steel, this gate is engineered to meet stringent quality standards, BS EN 10346, ensuring protection against rust in even the toughest conditions. The surface is then finished with a polyester powder coating compliant with BS EN 13438, offering deep resistance to weather damage, abrasion, and general wear while maintaining a visually striking appearance.
A wide selection of RAL-coordinated colours is available so you can match site aesthetics or branding needs.
Contact Us
Our sales team would love to help with installation advice, coloured finishes, or product sizing! Call us on 01283 512 111 or hop on our online chat for fast, friendly support.
Specifications & Downloads
| Height Above Ground | 2400mm |
| Access Width | 3500mm |
| Total Width | 3900mm |
| Hinge Post Size | 150mm x 150mm |
| Hinge Gap | 120mm |
| Leaf Gap | 30mm |
| Gate Hanging Side | Universally Handed |
| Post Type | Square Hollow Section |
| Gate Type | Single Leaf |
| Material | Pre-Galvanised Steel |
| Finish | Powder Coated |
| PPC Colours | Green & Black as Standard, Others Available On Request |
| Compliant To | Pre-Galvanised Steel to BS EN 10346 / Powder Coated to BS 13438 |
What's Included
| Name | Quantity |
|---|---|
| Apollo 358 Mesh Gate Leaf | 1 |
| Catch Gate Post | 1 |
| Hinge Gate Post | 1 |
| Adjustable Gate Eyes | 3 |
| Ribbed Inserts for Posts | 2 |
| HD Unislide Single Slider Padlockable Gate Kit | 1 |
| HD Apollo Plate Kit | 1 |
| HD Auto Locking Drop Bolt | 1 |
| 2.4m Clamp Bar [30x5mm @ 2430mm] | 2 |
| M8 x 100mm Nuts and Bolts | 18 |
