1.56m High DropCore Bollard
Yellow and Black 1.56m DropCore Bollard with mild steel socket
Product Description
1.56m High DropCore Bollard
The DropCore Bollards are a heavy-duty removable bollard system that can easily be integrated into a comprehensive impact protection system in a wide range of locations, including warehouses, factories and external level access loading doors where HGV trailers reverse in and out with deliveries daily.
Made from mild steel and hot dip galvanised to BS EN ISO 1461, the core of the DropCore Bollard has a finished height of 1560mm with an overall height measurement of 1700mm, and a diameter of 200mm.
This bollard comes with a cover kit made from brightly coloured polyethylene and has a 50mm reflective silver band for enhanced perceptibility when light levels are low. This cover has a diameter of 210mm and easily slides over the post once it is secured in place. The cover means that the bollard will not need to be repainted the way a standard steel bollard would be, saving both time and money.
The DropCore Bollard comes with a cast-in steel floor socket (200mm deep) for easy bollard installation and removal. To install, you drill the slab, cast in the ground socket and then drop the core into the socket. The socket comes with 3 safety anchors to secure in place (M10 x 120mm). Post Mix is recommended for pointing around the baseplate to secure and neaten the finish.
Features & Benefits
- Heavy-duty bollard with shock-absorbing gaiter to withstand impact from heavy vehicles
- Works like a potted bollard but with a demountable core
- Should damage occur, simply lift out and replace the bollard core
- Available in a range of colours
Contact Us
First Fence has a range of Crash and Impact Protection products designed to help keep people, buildings, equipment and vehicles safe in busy delivery and warehouse environments.
Please get in touch if you have any questions about any of these products. Our sales team are knowledgeable and friendly and will be happy to help you. We can be contacted by calling 01283 512 111 or by using the online chat tool.
Specifications & Downloads
| Height | 1560mm AFFL [1700mm Overall Height] |
| Diameter | 200mm [Core] |
| Ground Fixing | Floor Socket [Demountable] |
| Floor Socket Depth | 200mm |
| Material | Mild Steel [Core and Floor Socket], Polyethylene [Sleeve] |
| Finish | Hot Dip Galvanised |
| Compliant to | BS EN ISO 1461 [Galvanised] |
| Colour | Yellow and Black, Black and Yellow or Red and White |
Specifications & Downloads
| Height | 1560mm AFFL [1700mm Overall Height] |
| Diameter | 200mm [Core] |
| Ground Fixing | Floor Socket [Demountable] |
| Floor Socket Depth | 200mm |
| Material | Mild Steel [Core and Floor Socket], Polyethylene [Sleeve] |
| Finish | Hot Dip Galvanised |
| Compliant to | BS EN ISO 1461 [Galvanised] |
| Colour | Yellow and Black, Black and Yellow or Red and White |
Product Description
1.56m High DropCore Bollard
The DropCore Bollards are a heavy-duty removable bollard system that can easily be integrated into a comprehensive impact protection system in a wide range of locations, including warehouses, factories and external level access loading doors where HGV trailers reverse in and out with deliveries daily.
Made from mild steel and hot dip galvanised to BS EN ISO 1461, the core of the DropCore Bollard has a finished height of 1560mm with an overall height measurement of 1700mm, and a diameter of 200mm.
This bollard comes with a cover kit made from brightly coloured polyethylene and has a 50mm reflective silver band for enhanced perceptibility when light levels are low. This cover has a diameter of 210mm and easily slides over the post once it is secured in place. The cover means that the bollard will not need to be repainted the way a standard steel bollard would be, saving both time and money.
The DropCore Bollard comes with a cast-in steel floor socket (200mm deep) for easy bollard installation and removal. To install, you drill the slab, cast in the ground socket and then drop the core into the socket. The socket comes with 3 safety anchors to secure in place (M10 x 120mm). Post Mix is recommended for pointing around the baseplate to secure and neaten the finish.
Features & Benefits
- Heavy-duty bollard with shock-absorbing gaiter to withstand impact from heavy vehicles
- Works like a potted bollard but with a demountable core
- Should damage occur, simply lift out and replace the bollard core
- Available in a range of colours
