3.0m High x 4.0m Wide EnviroProtect® SR1 (A1) LPS 1175 Double Leaf Railing Gate Kit
Product Description
3.0m High x 4.0m Wide EnviroProtect® SR1 (A1) LPS 1175 Double Leaf Railing Gate Kit
When you need to secure a wide vehicle entrance with a maximum-height barrier, the 4.0m wide, 3.0m high EnviroProtect® Double Leaf Gate Kit is the definitive choice. This system is designed to control access for larger vans and lorries at the most secure facilities. It features uprated 100x100mm hinge posts for complete structural integrity across the wide span. With full LPS 1175 A1(SR1) certification, this gate provides uncompromising security for critical access points.
Our EnviroProtect gates are purpose-built to work seamlessly with EnviroProtect fencing, delivering a strong, reliable, and uniform perimeter.
Understanding A1(SR1) Rated Security Railings
The A1(SR1) rating provides certified proof of this gate's security capabilities. It verifies that the gate has withstood rigorous physical attack tests, proving its ability to delay an intruder for a critical period. This level of tested security is essential for protecting national infrastructure and high-value commercial assets.
Innovative Low to No Weld Construction
Engineered for maximum endurance, the gate's low-weld construction provides a clear advantage over traditionally welded products. By eliminating the points where rust typically forms, the design ensures superior structural integrity and corrosion resistance, leading to a significantly longer operational life with far less maintenance.
Technical Specification and Design
This heavy-duty gate is specified for wider openings requiring maximum security. It has a certified height of 3.0 metres, a clear access width of 4000mm, and a total overall width of 4430mm. Each of the two 60x60mm steel box section gate leaves is supported by an uprated, heavy-duty 100x100x3mm hinge post. The standard Polyester Powder Coated finish offers unparalleled protection against weathering.
Installation Options
This kit is designed to be securely installed in any location, coming complete with both bolt-down and dig-in post options. The 3000mm base-plated posts are for solid ground, while the 3700mm extended posts are for creating a deep concrete foundation, ensuring total stability for this substantial gate system.
Benefits and Applications
This gate is the premier choice for securing busy service yards and entrances to Critical National Infrastructure sites. The 3.0m height provides the ultimate anti-climb deterrent, making it suitable for locations such as utility compounds, MOD sites, and secure data storage facilities.
Get in Touch
Discuss your vehicle access requirements with our team today for guidance and a comprehensive quote. You can contact us by telephone on 01283 512 111 or send your enquiry via email to sales@firstfence.co.uk. Our team is also available on Live Chat through our website.
Specifications & Downloads
| Height | 3000mm [Installed] |
| Access Width | 4000mm |
| Total Width | 4430mm |
| Total Post Length | 3000mm [Bolt Down], 3700mm [Dig In] |
| Box Sections of Posts | 100x100x3mm [Hinge] |
| Box Section of Gate Leaf | 60x60mm |
| Rail Style | Vertical Bar - Hollow Tubular |
| Post Type | Dig In, Bolt Down |
| Material | Pre-Galvanised Steel to BS EN 10346 |
| Finish | Polyester Powder Coated |
| PPC Colours | Green, Black, Blue, Red, Grey or Yellow |
| Certified To | LPS 1175 SR1 (A1) |
What's Included
| Name | Quantity |
|---|---|
| EnviroProtect® Gate Leaf | 2 |
| 100x100mm Hinge Gate Post | 2 |
| Adjustable Gate Eyes | 6 |
| Large Twist Cleats | 6 |
| M10 Shear Nut | 6 |
| M10 x 120mm Bolts | 6 |
| Drop Bolt | 2 |
| 100x100mm Ribbed Inserts | 2 |
| M16 x 125mm Ground Anchors [Bolt Down] | 8 |
