2.4m High x 3.0m Wide EnviroProtect® SR1 (A1) LPS 1175 Double Leaf Railing Gate Kit
Product Description
2.4m High x 3.0m Wide EnviroProtect® SR1 (A1) LPS 1175 Double Leaf Railing Gate Kit
The 2.4m high x 3.0m wide EnviroProtect® Double Leaf Gate Kit is designed to safeguard sites where both vehicle access and high-security protection are critical. Its imposing 2.4m anti-climb height acts as a strong deterrent, while the 3.0m span provides ample clearance for light commercial vehicles and service traffic. Fully accredited to LPS 1175 A1 (SR1) and built using our low-weld construction method, this gate ensures reliable performance, exceptional durability, and minimal maintenance in demanding environments.
Our EnviroProtect gates are designed to integrate seamlessly with EnviroProtect fencing systems, ensuring consistent strength, security, and appearance across the entire perimeter.
Certified SR1 Security
Independently tested to LPS 1175 A1 (SR1), this gate has proven its ability to resist a sustained 60-second assault with common hand tools. This recognised certification offers peace of mind that your property and assets are protected with a security system trusted by industry professionals and insurers alike.
Low-to-No Weld Design
Traditional welded gates are prone to rust and weakness over time. The EnviroProtect® system overcomes this with precision-engineered mechanical fixings, which deliver superior strength, increased corrosion resistance, and a longer service life. As standard, the gate is pre-galvanised steel to BS EN 10346, with the option of a polyester powder coating in a wide range of RAL colours.
Height: 2.4m (certified)
Clear access width: 3000mm
Overall width (inc. posts): 3430mm
Gate frame: 60 x 60mm steel box section
Hinge posts: 80 x 80 x 3mm heavy-duty steel
Finish: Pre-galvanised steel
Installation Options
Supplied with post options for flexibility on any site:
- 2400mm base-plated posts: for bolt-down installation onto concrete
- 3100mm dig-in posts: for setting into new concrete foundations
Benefits & Applications
This high-security double leaf gate is particularly suited to:
- Industrial estates
- Research and development facilities
- Commercial depots
- Secure compounds
The 2.4m height provides a commanding security presence, while the 3.0m clear width makes it practical for frequent vehicle access.
Get in Touch
Ready to secure your site? Contact our team for technical data sheets, quotations, and expert advice. Call us on 01283 512 111, email sales@firstfence.co.uk, or connect with us via Live Chat on our website.
Specifications & Downloads
| Height | 2400mm [Installed] |
| Access Width | 3000mm |
| Total Width | 3430mm |
| Total Post Length | 2400mm [Bolt Down], 3100mm [Dig In] |
| Box Sections of Posts | 100x100x3mm [Hinge] |
| Box Section of Gate Leaf | 60x60mm |
| Rail Style | Vertical Bar - Hollow Tubular |
| Post Type | Dig In, Bolt Down |
| Material | Pre-Galvanised Steel to BS EN 10346 |
| Finish | Polyester Powder Coated |
| PPC Colours | Green, Black, Blue, Red, Grey or Yellow |
| Certified To | LPS 1175 SR1 (A1) |
What's Included
| Name | Quantity |
|---|---|
| EnviroProtect® Gate Leaf | 2 |
| 100x100mm Hinge Gate Post | 2 |
| Adjustable Gate Eyes | 6 |
| Large Twist Cleats | 6 |
| M10 Shear Nut | 6 |
| M10 x 120mm Bolts | 6 |
| Drop Bolt | 2 |
| 100x100mm Ribbed Inserts | 2 |
| M16 x 125mm Ground Anchors [Bolt Down] | 8 |
Specifications & Downloads
| Height | 2400mm [Installed] |
| Access Width | 3000mm |
| Total Width | 3430mm |
| Total Post Length | 2400mm [Bolt Down], 3100mm [Dig In] |
| Box Sections of Posts | 100x100x3mm [Hinge] |
| Box Section of Gate Leaf | 60x60mm |
| Rail Style | Vertical Bar - Hollow Tubular |
| Post Type | Dig In, Bolt Down |
| Material | Pre-Galvanised Steel to BS EN 10346 |
| Finish | Polyester Powder Coated |
| PPC Colours | Green, Black, Blue, Red, Grey or Yellow |
| Certified To | LPS 1175 SR1 (A1) |
What's Included
| Name | Quantity |
|---|---|
| EnviroProtect® Gate Leaf | 2 |
| 100x100mm Hinge Gate Post | 2 |
| Adjustable Gate Eyes | 6 |
| Large Twist Cleats | 6 |
| M10 Shear Nut | 6 |
| M10 x 120mm Bolts | 6 |
| Drop Bolt | 2 |
| 100x100mm Ribbed Inserts | 2 |
| M16 x 125mm Ground Anchors [Bolt Down] | 8 |
Product Description
2.4m High x 3.0m Wide EnviroProtect® SR1 (A1) LPS 1175 Double Leaf Railing Gate Kit
The 2.4m high x 3.0m wide EnviroProtect® Double Leaf Gate Kit is designed to safeguard sites where both vehicle access and high-security protection are critical. Its imposing 2.4m anti-climb height acts as a strong deterrent, while the 3.0m span provides ample clearance for light commercial vehicles and service traffic. Fully accredited to LPS 1175 A1 (SR1) and built using our low-weld construction method, this gate ensures reliable performance, exceptional durability, and minimal maintenance in demanding environments.
Our EnviroProtect gates are designed to integrate seamlessly with EnviroProtect fencing systems, ensuring consistent strength, security, and appearance across the entire perimeter.
Certified SR1 Security
Independently tested to LPS 1175 A1 (SR1), this gate has proven its ability to resist a sustained 60-second assault with common hand tools. This recognised certification offers peace of mind that your property and assets are protected with a security system trusted by industry professionals and insurers alike.
Low-to-No Weld Design
Traditional welded gates are prone to rust and weakness over time. The EnviroProtect® system overcomes this with precision-engineered mechanical fixings, which deliver superior strength, increased corrosion resistance, and a longer service life. As standard, the gate is pre-galvanised steel to BS EN 10346, with the option of a polyester powder coating in a wide range of RAL colours.
Height: 2.4m (certified)
Clear access width: 3000mm
Overall width (inc. posts): 3430mm
Gate frame: 60 x 60mm steel box section
Hinge posts: 80 x 80 x 3mm heavy-duty steel
Finish: Pre-galvanised steel
Installation Options
Supplied with post options for flexibility on any site:
- 2400mm base-plated posts: for bolt-down installation onto concrete
- 3100mm dig-in posts: for setting into new concrete foundations
Benefits & Applications
This high-security double leaf gate is particularly suited to:
- Industrial estates
- Research and development facilities
- Commercial depots
- Secure compounds
The 2.4m height provides a commanding security presence, while the 3.0m clear width makes it practical for frequent vehicle access.
