2.0m High x 4.0m Wide AcoustiGuard® SR1 (A1) LPS 1175 Double Leaf Gate Kit
Product Description
2.0m High x 4.0m Wide AcoustiGuard® SR1 (A1) LPS 1175 Double Leaf Gate Kit
For sites with a wide entry point, the AcoustiGuard® SR1 Double Leaf Gate Kit provides the ideal balance of strength, access, and sound control. With a generous 4.0-metre span and a secure 2.0-metre height, it easily accommodates larger vehicles such as delivery trucks and service vans. Supplied as a single pre-assembled unit, the gate is ready to be craned into position, ensuring quick and straightforward installation. This makes it a preferred choice for logistics hubs, utilities, and any facility where certified protection must work with advanced acoustic performance.
About LPS 1175 Certification
Security is assured through the gate’s LPS 1175 SR1 (A1) rating. This certification, issued by the Loss Prevention Certification Board, proves that the gate has successfully resisted a simulated break-in attempt. The SR1 (A1) test consists of a professional attempting to gain entry within one minute using a defined set of basic tools often linked with opportunistic crime. Passing this benchmark demonstrates that the gate provides a vital deterrent and critical delay, supporting a layered approach to site security.
Compliance with BS EN 1794-1 and BS EN 1794-2
This system has been engineered not just for security but also for acoustic and structural excellence. Tested against BS EN 1794-1, the gate’s timber frontage has been designed to absorb and reduce noise levels, supporting compliance with environmental regulations and minimising disruption to surrounding communities. BS EN 1794-2 testing ensures the structure’s reliability and durability, with robust 120x120x4mm posts and a galvanised steel frame designed to withstand both physical impact and environmental exposure.
Technical Details
- Kit Delivery: Supplied fully assembled for straightforward lifting and positioning.
- Height: Installed height of 2000mm (2.0m).
- Width: Provides a clear 4000mm (4.0m) opening for vehicles.
- Posts: 120x120x4mm box section steel posts for strength and stability.
- Leaf Configuration: Standard set-up is right-hand hung (viewed from outside).
- Materials: A combination of hot dip galvanised steel (ISO 1461 compliant) and UC4 treated timber for noise reduction and rot protection.
Certification: Independently tested to LPS 1175 SR1 (A1).
Contact Us
For more information about AcoustiGuard® or our other SR1 (A1) LPS 1175 rated solutions, please get in touch. The friendly First Fence experts are available by phone on 01283 512 111 or by email at sales@firstfence.co.uk. You can also connect via our live chat service for more details.
Specifications & Downloads
| Kit Type | Assembled [Fully Assembled for Lifting] |
| Height | 2000mm [Installed] |
| Access Width | 4000mm |
| Box Sections of Posts | 120x120x4mm |
| Gate Hanging Side | Right Hand Hung [From Outside Looking In] |
| Material | Hot Dip Galvanised Steel [Gate Frame] Tanalised UC4 Timber [Acoustic Face] |
| PPC Colours | Galvanised Only |
| Compliant To | ISO 1461 [Galvanising] |
| Certified To | LPS 1175 SR1 (A1) |
What's Included
| Name | Quantity |
|---|---|
| Sliding Gate Leaf | 1 |
| Catch Gate Leaf | 1 |
| Hinge Post | 2 |
| SR1 Adjustable Gate Eyes | 6 |
| Ribbes Inserts [For Gate Posts] | 2 |
| Ribbed Inserts [For Gate Frame] | 4 |
| Drop Bolt | 2 |
| AcoustiGuard® Absorb Timber Infill | 2 |
