2.4m x 4.0m Wide ProFence® SR1 (A1) LPS 1175 868 Mesh Single Gate Leaf Kit
| Height | 2400mm [Installed] |
| Access Width | 4000mm |
| Box Sections of Posts | 150 x 150mm Hinge Post, 100 x 100mm Catch Post |
| Gate Hanging Side | Right Hand Hung [From Outside Looking In] |
| Thickness of Wires | [Horizontal: 8mm] [Vertical: 6mm] |
| Material | Hot Dip Galvanised Steel |
| PPC Colours | Available in Green, Black, Blue, Red, Grey, & Yellow - Other custom RAL colours are available |
| Compliant To | ISO 1461 |
| Name | Quantity |
|---|---|
| Sliding Gate Leaf | 1 |
| Catch Post | 1 |
| Hinge Post | 1 |
| SR1 Adjustable Gates Eyes | 3 |
| Ribbed Inserts [For Gate Posts] | 2 |
| Ribbed Inserts [For Gate Frame] | 2 |
| Drop Bolt | 1 |
| Ground Anchor Bolts [Bolt Down Version] | 8 |
2.4m x 4.0m Wide ProFence® SR1 (A1) LPS 1175 868 Mesh Single Gate Leaf Kit
In situations where protecting assets of high-value, sensitive information or products is of paramount importance, premium security is an absolute necessity. ProFence® SR1 (A1) LPS 1175 868 Fencing and Gates stand as the pinnacle of First Fence's offerings, making them the ideal choice for such scenarios.
Understanding SR1 (A1) Rated Security Fencing
To achieve this accreditation, products undergo a rigorous testing and scrutiny process, meticulously evaluating their ability to withstand aggressively deliberate attacks. This evaluation includes testing the product's resilience against tools like bolt cutters, screwdrivers, pliers, and others from Toolkit A. These are easily concealed tools that an opportunistic vandal may have at their disposal. This process not only assesses the product's resistance to security breaches but also measures the time an intruder is willing to invest in attempting to break in.
The SR1 (A1) rating attests that the product offers resistance to a sustained sixty-second attack. These critical seconds are pivotal, enabling on-site security teams to detect, respond, and take necessary action before the perimeter is compromised.
The Versatile ProFence® Range
First Fence's ProFence® range offers a choice of fence kits, including the 358 Prison Mesh and 868 Twin Mesh, each available in various heights. To complement these options, there are single and double gates designed to integrate with the ProFence® fencing system. This product range has rightfully earned its reputation as an exceptional security solution, firmly securing its place in the esteemed Red Book, courtesy of rigorous SR1 testing.
Features and Benefits
The 2.4m x 4.0m Wide ProFence® gate comes in kit form and seamlessly aligns with the ProFence® fencing range of the same height. The kit includes a sliding gate leaf equipped with a secure latch bolt for closure, a hinge and catch post, three adjustable gate eyes with shear nuts, ribbed inserts for the posts and gate frame, and a padlock to bolster security. Moreover, it provides 50mm ground clearance..
TheseSR1-rated mesh gate is fabricated from high-quality steel, hot dip galvanised to ISO 1461 standards. This ensuring long-lasting protection against the elements and any potential damage – an indispensable attribute for a gate permanently established outdoors. Additionally, a polyester powder coating not only gives a sleek finish but also enhances resistance against damage. The fencing and gates are available in a selection of RAL colours including green and black.
The ProFence® 868 Mesh gate showcases the distinctive 868 Twin Mesh, characterised by 6mm vertical wires intersecting with 8mm horizontal wires. This mesh configuration offers not only robustness and resistance against cutting but also exceptional visibility while effectively preventing the passage of items.
Safety remains a top priority with this certified mesh gate, featuring three adjustable gate eyes. Even in the event of one hinge point failing, the gate itself remains secure, safeguarding both people and property from harm. Each gate eye is securely fastened with a shear nut, ensuring tamper-proof security.
For enhanced security, the gate can be firmly closed using the sliding latch bolt. The kit also incorporates a drop bolt designed to securely hold the gate in the open position, featuring an M5x20mm one-way pan head bolt and M5 shear nut to deter unauthorised removal.
ProFence® is certified for gradients from 0 to 25 degrees.
Ease of Installation
The ProFence® gate offers installation flexibility, available in either a dig-in or bolt-down format. It is essential to evaluate your ground conditions before making the installation choice. The bolt-down option includes four ground anchor bolts for each post, while the dig-in post option requires Post Mix, available for separate purchase. For a 2.4m high gate, it is recommended to utilise four bags of Post Mix per post to establish a solid foundation. It is highly recommended that you use either C20 or C25 post mix.
It is suggested that you use either C20 or C25 post mix.
